n Product Features
l Extremely low insertion loss
l Compact size
l Low channel crosstalk
l High stability
n Applications
l Passive Optical Networks (PON)
l Optical protection systems
l Measurement systems
l Network monitoring
n Specifications
Optical Performance/光学性能 | Specification | ||
Operation Wavelength/工作波长 | nm | 1550.00 | |
Insertion Loss /插入损耗 | Typ | dB | 0.80 |
Return Loss/回波损耗 | min | dB | 55 |
Cross-talk/串扰 | min | dB | 55 |
Switch Mode/控制方式 | Latching | ||
Power supply/驱动电压 | V | 5 | |
Fiber Type/光纤类型 | PM | ||
Dimensions/尺寸 | mm | 27X12.6X8.5 | |
Operating Temperature/工作温度 | oC | -20~70 | |
Temperature Cycling (Temperature Range / Cycles)/温度循环 | C / Hr | -40℃ to +85℃/48Hr | |
Data Document Preparation/数据文档制备 | Specification | ||
Individual Test Data Sheet Format/单独测试数据单格式 | Hardcopy | Neutral | |
Electronic Media Test Data File Format/电子媒介测试文件格式 | MS-Word | Neutral | |
RoHS Required/是否需要过RoHS | Yes/No | No | |
Pigtail Type/尾纤类型 | 0.9mm | ||
Pigtail Length/尾纤长度 | 0.5 | ||
Connector Type/连接头类型 | FO/APC | ||
n Ordering Information: OSW—A—B—C—D—E—F
A | B | C | D | E | F |
Wavelength | Fiber Type | Voltage | Ferrule | Patch Cord Length | Connector |
13: 1310nm 15: 1550nm 13/15: 1310+1550nm X: Other | SM: Single Mode X: Other | 5-5V | 025: Φ0.25mm 09: Φ0.9mm X: Other | 05: 0.5m 10: 1.0m 15: 1.5m X: Other | 1: SC/UPC 2: SC/APC 3: LC/UPC 4: FC/UPC 5: FC/APC |
Example Model:OSW-113-SM-5-025-05-1
Description:Wavelength: 1310nm, Fiber Type: Single Mode, Voltage: 5V, Ferrule: Φ0.25mm, Patch Cord Length: 0.5m, Connector: SC/UPC.
For custom components, please provide detailed requirements.
