Applications
l EDFA
l Pump Laser
l Q-Switched Laser
Features
l Low Insertion Loss
l High Return Loss
l High Reliability & Stability
Specifications
Parameter | Unit | Values |
Center Wavelength | nm | 1550 |
Operating Wavelength Range | nm | ±30 |
Beam Diameter | mm | 4~6+/-1 |
Working Distance | mm | 100 |
Typ. Insertion Loss | dB | 0.4 |
Max. Insertion Loss | dB | 0.6 |
Max. PDL | dB | 0.1 |
Min. Return Loss | dB | 55 |
Fiber Type | / | LMA-GDF-25/30 |
Max.Optical Power | W | 100 |
Tensile Load | N | 5 |
Fiber Jacket Length | m | 2 |
Bare Fiber Length | m | 1 |
Operating Temperature | ℃ | -5 to +65 |
Storage Temperature | ℃ | -40 to +85 |
Remark:
* Above specifications are for device without connector.
Ordering Information: HPMCOLL -A-B-C-D-E
A | B | C | D | E |
HPC | Wavelength | Pigtail Type | Fiber Length | Connector |
1550=1550nm S=Specify | 001=250um bare fiber 002=900um loose tube SSS=Specify | 0.5=0.5m 1.0=1m 1.5=1.5m 2=2m S=Specify | N=None 0=FC/APC 1=FC/UPC 2=SC/APC 3=SC/UPC 4=LC/UPC S=Specify |
