Features
= Low loss and high reliability
= Parallel interface (TTL,RS485,RS232)
= Modularized design
= Epoxy-free in optical path
Applications
= Ring network
= Remote monitoring in optical network
= Testing of fiber optical component
Specifications
Optical Performance/光学性能 | Specification | ||
Operation Wavelength/工作波长 | nm | 850.00 | |
Insertion Loss /插入损耗 | Typ | dB | 0.80 |
Return Loss/回波损耗 | min | dB | 50 |
Cross-talk/串扰 | min | dB | 50 |
Switch Mode/控制方式 | |||
Power supply/驱动电压 | V | 5 | |
Fiber Type/光纤类型 | 50/125 | ||
Dimensions/尺寸 | mm | 135*64*32 | |
Operating Temperature/工作温度 | oC | -20~70 | |
Temperature Cycling (Temperature Range / Cycles)/温度循环 | C / Hr | -40℃ to +85℃/48Hr | |
Data Document Preparation/数据文档制备 | Specification | ||
Individual Test Data Sheet Format/单独测试数据单格式 | Hardcopy | Neutral | |
Electronic Media Test Data File Format/电子媒介测试文件格式 | MS-Word | Neutral | |
RoHS Required/是否需要过RoHS | Yes/No | No | |
Pigtail Type/尾纤类型 | 2 | ||
Pigtail Length/尾纤长度 | 1m | ||
Pigtail Mark Method/尾纤标识方法 | Fiber Color | ||
Connector Type/连接头类型 | MPO/PC Male | ||
Dimensions
Ordering Information: OSW-1×N－A－B－C－D－E－F－G
N | A | B | C | D | E | F | G |
Fiber Type | Test Wavelength | sheath | Fiber Length | Connector | Control port | Size | |
SM: SM, 9/125 M5: MM50/125 M6: MM62.5/125 Hi:Hi1060 | 850: 850nm 1310: 1310nm 1550: 1550nm 13/15:1310/1550nm XX：othe | 25:250um 90: 900um 20: 2.0mm FA:fiber array | 05: 50±5cm 10: 100±5cm 15: 150±5cm | OO:None FP: FC/PC FA: FC/APC SP: SC/PC SA: SC/APC LP: LC/PC LA: LC/APC ST:ST/PC | 01: TTL+RS232 02:TTL+RS485 03:USB | A:135X40X32 B:135X64X32 |
